SRF3W077 Lotti Wi-Fi 6E/7 Flexible PCB Antenna with Cable

This flexible PCB antenna is designed for Wi-Fi 6E and Wi-Fi 7 applications, providing broad coverage across the 2.4–2.5GHz, 4.9–5.9GHz, and 5.925–7.125GHz bands. Its compact form factor and self-adhesive mounting make it easy to integrate into a wide range of devices. The included cable and I-PEX MHF connector enable a straightforward plug-and-play installation to the host PCB, minimizing design cycles and simplifying assembly.

• Flexible PCB construction for versatile placement
• Self-adhesive backing for quick and secure mounting
• Supplied with 100mm RF cable and I-PEX MHF connector for easy connection

Applications

WiFi6E & WiFi7 Routers, WiFi6E & WiFi7 surveillance cameras, USB dongles for WiFi6E & WiFi7, Game Consoles, Set-Top Boxes, Network Devices, MIMO Systems

Technical Specifications

Operating Temperature: -40°C to +85°C
Frequency Range: 2400-2500, 4900-5900, 5925-7125 MHz
Standards: 802.11a/b/g/j/n/ac/ax
VSWR: 1.3:1 (2.4GHz), 1.6:1 (5GHz), 1.5:1 (6GHz)
Efficiency (%): 70% (2.4GHz), 65% (5GHz), 70% (6GHz)
Peak Gain (dBi): 2.8 (2.4GHz), 3.2 (5GHz), 4.4 (6GHz)
Impedance (Ohm): 50
Polarisation: Linear
Mounting: Adhesive Mount
Type: Single
