Description
This high-performance screw mount antenna is designed for reliable operation in demanding environments, supporting Wi-Fi, Bluetooth, ZigBee, and ISM applications in the 2.4 GHz band. Its robust construction and ground plane independence make it ideal for smart home, industrial, transportation, and IoT deployments where durability and consistent connectivity are essential. The antenna is protected with IP67 and IP69K ratings, ensuring resistance to dust and water ingress for both indoor and outdoor installations.
Connections
2.4GHz/WiFi/LPWA/BT/ZigBee/RFID/ISM
Technical Specifications
Operating Temperature: -40 °C to +85 °C
Mounting: Screw Mount
Location: External
Type: Single
Short-Range Wireless Standards: Wi-Fi, Bluetooth, ZigBee, ISM
Connection 1 - 2.4 GHz ISM
Standards: WiFi, BT, ZigBee, ISM
Frequency: 2410-2490 MHz
VSWR: ~2.0:1
Efficiency (%): ~41.5
Peak Gain (dBi): ~3.9
Impedance (Ohm): 50
Polarisation: Linear
Max. Input Power (W): 25
