Description
This compact active GNSS patch antenna module is designed for embedded (inside-device) integration where high sensitivity is required. A two-stage LNA and front-end SAW filter help improve reception and reduce susceptibility to nearby cellular transmitter interference, supporting reliable GPS/Galileo positioning in small devices.
- Embedded GNSS module design: suited for integration inside compact products
- Two-stage LNA + SAW filter: enhanced sensitivity and improved out-of-band rejection
- Wide supply range: supports operation across common GNSS receiver bias voltages
Connector & Cable
- Connector Type: I-PEX MHF I (U.FL)
- Cable Length: 4.5cm
- Cable Type: Ø1.13 coax
Installation / Environmental
4. Plugs Usage and Precautions
4.1. Mating / Un-mating
(1) To disconnect connectors, insert the end portion of I-PEX under the connector flanges and pull off vertically, in the direction of the connector mating axis.
(2) To mate the connectors, the mating axes of both connectors must be aligned and the connectors can be mated. The "click" will confirm fully mated connection. Do not attempt to insert on an extreme angle.
4.2. Pull forces on the cable after connectors are mated
After the connectors are mating, do not apply a load to the cable in excess of the values indicated in the diagram below.
Technical Specifications
Operating Temperature: -40°C to +85°C
Antenna Technologies: Patch
Location: Internal
Mounting: Cable Mount
Satellite Navigation: GNSS
Type: Single
Dimensions: 13.4*13.4*6mm
Weight: 22g
GNSS (Active)
Frequency: 1575.42 ± 1.023MHz
GNSS Bands: L1
Impedance: 50Ω
Polarization: RHCP
VSWR: 2
Gain (Max): 29
Input Voltage: Min. 1.8V Typ 3.0V Max. 5.5V
Connector Type: I-PEX MHF I (U.FL)
Cable Length: 4.5cm
Cable Type: 1.13 Coax
