Description
This compact 5.8GHz cable dipole antenna is designed for embedded integration where space and weight are critical. Its omnidirectional radiation pattern and high efficiency help deliver a more reliable Wi-Fi link for UAV and FPV (First-Person View) applications.
- Designed for compact devices: lightweight, thin, and easy to attach
- Reliable link performance: omnidirectional coverage with high efficiency
- Integration-friendly routing: cable exits from the bottom to minimize required device volume
Connector & Cable
- Connector Type: I-PEX MHF I (U.FL) Connector
- Cable Length: 10cm
- Cable Type: Ø1.37mm coaxial cable
Technical Specifications
Operating Temperature: -40°C to +85°C
Antenna Technologies: Dipole
Location: Internal
Mounting: Cable Mount
Short-Range Wireless Standards: Wi-Fi
Type: Single
Dimensions: 25 (Ma x imum Diameter: 4.7mm)
Weight: 1.01g
Wi-Fi (5.15–5.85GHz)
Frequency: 5150-5850 MHz
Standards: Wi-Fi
Polarization: Linear
Impedance: 50 Ohms
VSWR (Max): 2:1
Return Loss (Max): <-10 dB
Peak Gain: 3.94 dBi
Efficiency: 70.92%
Average Gain: -1.50 dBi
Radiation Properties: Omnidirectional
Max Input Power: 2 W
Connector Type: I-PEX MHF I (U.FL)
Cable Length: 10cm
Cable Type: Ø1.37mm coaxial cable
