FW.86.B.NTY.M Antenna Outdoor External ISM, LoRa flexible whip Meteor N-Type(M) IP65 for Weather Monitoring, Motion/Vibration Sensors, Pollution Monitoring, Border Guard Monitoring

Flexible 868MHz whip antenna for outdoor ISM/LoRa deployments. This rugged external antenna is designed to deliver strong efficiency and high peak gain at 868MHz, helping improve link reliability and reduce device power consumption during data transmission.

• Rugged, abrasion-resistant construction with an inner steel core
• Flexible whip design to help maintain shape and RF performance in the field
• Built for outdoor environments with dust and water resistance
• Well-suited for weather monitoring systems, motion/vibration sensors, pollution monitoring, and border guard monitoring systems

Connector & Cable

• Connector Type: N-Type Male Connector

Technical Specifications

Operating Temperature: -40°C to 80°C
Antenna Technologies: Monopole, Whip
Location: External
LPWAN & IoT Communication: LoRa
Mounting: Terminal Mount
Short-Range Wireless Standards: ISM
Type: Single
IP Rating: IP65
Frequency: 860MHz - 880MHz
Center Frequency: 868MHz
Impedance: 50Ω
Polarization: Linear
Radiation Pattern: Omnidirectional
VSWR: 2:1
Gain (Max): 2.8dBi
Input Power: 2 W
Tested Power: 10 W
Dimensions: 243 ± 5.3mm
Base Diameter: 20 ± 0.6mm
Whip Diameter: 6.2 ± 0.6mm
Connector Type: N Type(M) Straight
Weight: 48.5g
