FXUB71.A.07.C.001 Antenna 2x2 MIMO Wideband 5G, 4G/LTE flex PCB for Gateways and Routers, High speed HD streaming, Wireless Access Points, Handheld Devices

Flexible PCB antenna designed for embedded wideband cellular devices where space, placement flexibility, and MIMO performance are critical. The slim flexible polymer structure supports efficient wideband operation and is engineered to maintain strong isolation between the two MIMO ports for reliable throughput.

• Embedded wideband cellular coverage for modern 5G/4G devices
• 2x2 MIMO design to support higher data rates and improved link reliability
• Flexible, low-profile form factor for easier integration into compact housings
• Peel-and-stick installation concept using adhesive backing for fast placement inside plastic enclosures

Typical use cases include gateways and routers, high speed HD streaming equipment, wireless access points, handheld devices, and high capacity MIMO networks for public transportation.

For best performance, mount onto a plastic housing and keep the antenna at least 10mm from metal components or surfaces (20mm recommended where possible). Cable routing should avoid cross-over to support a clean, repeatable integration.

Technical Specifications

Operating Temperature: -40°C to 85°C
Antenna Technologies: Monopole, MIMO
Cellular Technologies: 5G
Location: Internal
LPWAN & IoT Communication: NB-IoT, Cat-M
Mounting: Adhesive Mount
Type: Combination
Mechanical Style: Flex PCB
Dimensions: 240mm*21mm*0.15mm
Weight: 4.2g
Impedance: 50 Ω
Polarization: Linear
VSWR: 2:1
Gain (Max): 3.85 dBi
Material: Flexible Polymer
Adhesive: 3M 467

5G/4G MIMO (Port 1)

Frequency: 600MHz - 6000MHz
Standards: 5GNR/4G/3G/2G
Max Input Power: 2W
Radiation Pattern: Omni-Directional
Connector Type: I-PEX MHF I (U.FL Compatible)
Cable Length: 15cm
Cable Type: Ø1.37 Coaxial cable

5G/4G MIMO (Port 2)

Frequency: 600MHz - 6000MHz
Standards: 5GNR/4G/3G/2G
Max Input Power: 2W
Radiation Pattern: Omni-Directional
Connector Type: I-PEX MHF I (U.FL Compatible)
Cable Length: 15cm
Cable Type: Ø1.37 Coaxial cable
