Description
This external Iridium marine antenna is built for durable, permanent installations where reliable satellite communications performance is required.
- Marine-ready durability: IP67-rated housing for harsh environments.
- Permanent installation support: Designed for bracket/wall mounting use cases.
- Free-air operation: No ground plane required.
- Commercial system compatibility: Certified for use with the Iridium communications system (as stated in the product documentation).
Connector & Cable
- Connector Type: SMA-M
- Cable Length: 100cm
- Cable Type: CFD-200
Technical Specifications
Operating Temperature: -40°C to +85°C
Location: External
Mounting: Wall Mount, Bracket Mount, Screw Mount
Type: Single
IP Rating: IP67
Dimensions: Profile:108mm*Ø90mm
Weight: 108g
Iridium (NTN/SatCom)
Frequency: 1616MHz - 1626.5MHz
Center Frequency: 1621.5±5.25MHz
Impedance: 50 Ohms
Polarization: Right Hand Circular
VSWR: 2:1
Efficiency (%): 75.6 (1.0 meter cable)
Peak Gain (dBi): 3.9 (1.0 meter cable)
Return Loss (dB): -10.5 (1.0 meter cable)
Connector Type: SMA (M)
Cable Length: 100cm
Cable Type: CFD-200
