Description
External, omnidirectional 4G/LTE antenna designed for reliable cellular connectivity across a wide range of global bands. Its flat blade-style housing is built for robust performance in demanding deployments where consistent uplink/downlink performance is required.
Ideal for long-cable installations, the antenna is engineered to support efficient, stable performance for connected systems deployed on infrastructure, equipment, and remote sites.
- Use cases: telematics, transportation systems, and remote monitoring
- Design: compact blade form factor with omnidirectional coverage
- Durability: IP67-rated waterproof enclosure for harsh environments
Connector & Cable
- Connector Type: SMA-M
- Cable Length: 500cm
- Cable Type: CFD-200
Technical Specifications
Operating Temperature: -40°C to 85°C
Antenna Technologies: Dipole
Cellular Technologies: 4G/LTE
Location: External
Mounting: Wall Mount, Pole Mount
Type: Single
IP Rating: IP67
Dimensions: 335.5*45*157mm E x ternal Bracket Mount Antenna Robust design for all weather oper
Weight: 220g
Cellular (4G LTE / 3G / 2G)
Frequency: 698~806, 824~894, 880~960, 1710~1880, 1850~1990, 1920~2170, 2300~2690 MHz
Standards: LTE700, GSM850, GSM900, DCS, PCS, UMTS1, LTE2600
Impedance: 50Ω
VSWR: 1.5
Polarization: Linear
Gain (Max): 2.7
Connector Type: SMA(M)
Cable Length: 500cm
Cable Type: CFD-200
