Description
The Stream MA.208 is a low-profile, heavy-duty external antenna that combines GNSS (GPS/Galileo) and cellular (4G/3G/2G) performance in a compact adhesive-mount format. It is designed for demanding field deployments where consistent efficiency, strong peak gain, and reliable isolation are required.
- 2-in-1 combination design: GNSS positioning plus wideband cellular connectivity in one rugged housing
- Low-profile, waterproof enclosure: suited to harsh outdoor environments
- Optimized for professional deployments: supports telematics, transportation, and remote monitoring use cases
Connections
1x GPS/GALILEO (L1 1575.42MHz)
1x 4G/3G/2G (700-960MHz / 1710-2170MHz)
Installation / Environmental
The Stream works best when attached to plastic or glass, but can also be used on metal if some foam spacing is added.
Technical Specifications
Operating Temperature: -40°C to +85°C
Antenna Technologies: Patch, PIFA
Cellular Technologies: 4G/LTE
Location: External
Mounting: Adhesive Mount
Satellite Navigation: GNSS
Type: Combination
IP Rating: IP-67
Dimensions: 200.5*66.5*9mm
Weight: 180g
Storage Temperature: -40°C to +85°C
Relative Humidity: 20% to 95%
Housing: UV resistant PVC
GNSS (GPS/GALILEO)
Frequency: 1575.42 ± 1.023MHz
Features: 35*35*4mm ceramic patch antenna with two stage high gain LNA
Gain: 3.5dBic typ @ Zenith
Polarization: RHCP
Impedance: 50Ω
Connector Type: Fakra Code C (Blue)
Cable Length: 300cm
Cable Type: RG-174
Cellular (LTE/GSM/UMTS; 4G/3G/2G)
Frequency: 700MHz~960MHz, 1710MHz~2170MHz
Gain (Peak): 2.16dBi at 700-960MHz; 0.42dBi at 1710-2170MHz
Gain (Average): -3.03dBi at 700-960MHz; -4.34dBi at 1710-2170MHz
Efficiency (Average): 60% at 700-960MHz; 48% at 1710-2200MHz
Polarization: Linear
VSWR: 3.3 Max. at 700-960MHz; 3.6 Max. at 1710-1850MHz; 2.2 Max. at 1880-2170MHz
Impedance: 50Ω
Connector Type: Fakra Code D (Violet)
Cable Length: 300cm
Cable Type: CFD-200
