Description
Stream MA230 is a low-profile, heavy-duty external 3-in-1 antenna that combines satellite navigation, cellular connectivity, and Wi-Fi into a single rugged housing.
Designed to simplify device integration and reduce the number of separate antennas required, it supports reliable positioning and wireless communications in demanding environments. Typical use cases include telematics, transportation systems, and remote monitoring deployments.
The enclosure is waterproof and suited to long-term outdoor/vehicle installations using an adhesive mounting approach.
Connections
1x GPS/GLONASS/Galileo 1575/1602MHz
1x 4G/3G/2G Cellular 698-2170MHz
1x Wi-Fi/Public Safety/ZigBee 2.4/4.9~6GHz
Technical Specifications
Operating Temperature: -40°C to +85°C
Antenna Technologies: Patch
Cellular Technologies: 4G/LTE
Location: External
Mounting: Adhesive Mount
Satellite Navigation: GNSS
Short-Range Wireless Standards: Wi-Fi, ZigBee, ISM
Type: Combination
IP Rating: IP67
Dimensions: 200.5* 66.5*9mm Waterproof IP67 Rated
Weight: 180g
GNSS (GPS/GLONASS/Galileo)
Frequency: 1575.42MHz, 1602MHz
Standards: GPS/GLONASS/Galileo
Polarization: RHCP
Impedance: 50Ω
VSWR: 1.21 Max at 1575MHz; 1.55 Max at 1602MHz
Gain: 1.92dBi typ @ Zenith (1575.42MHz); 3.19dBi typ @ Zenith (1602MHz)
Connector Type: SMA(M)
Cable Length: 300cm
Cable Type: RG-174
Cellular (4G/3G/2G)
Frequency: 698-2170MHz
Standards: 4G/3G/2G (4G with 3G/2G fallback)
Impedance: 50Ω
VSWR: 3.3 Max at 700-960MHz; 3.6 Max at 1710-1850MHz; 2.2 Max at 1880-2170MHz
Gain: Average -3.03dBi at 700-960MHz; -4.34dBi at 1710-2170MHz; Peak 2.16dBi at 700-960MHz; 0.42dBi at 1710-2170MHz
Connector Type: SMA(M)
Cable Length: 300cm
Cable Type: Low Loss CFD200
Wi-Fi (Dual Band)
Frequency: 2.4/4.9~6GHz
Standards: Wi-Fi, Public Safety, ZigBee
Impedance: 50Ω
VSWR: 2.30 Max at 2400MHz; 1.08 Max at 5000MHz
Gain: 1.5dBi typ @2450MHz; 2.0dBi typ.@5000MHz
Connector Type: RP-SMA(M)
Cable Length: 300cm
Cable Type: Low Loss CFD200
