MA411.A.LBI.001 Antenna External 2x MIMO 4G/LTE, GNSS screw mount Storm 3-in-1 IP67 for Automotive and Heavy Equipment Vehicle Tracking and Telematics, Remote Asset and Pipeline Monitoring, HD Video over LTE, First Responder and Emergency Services

Storm MA411 is a rugged, super low-profile, IP67-rated external antenna designed for demanding telematics and M2M deployments that need both high-performance cellular connectivity and accurate multi-constellation positioning.

Its 3-in-1 design combines 2x LTE MIMO for reliable uplink/downlink performance with an active GNSS element supporting GPS, GLONASS, Galileo, and BeiDou to improve tracking stability and location accuracy—particularly in challenging real-world environments.

• 3-in-1 performance: cellular MIMO plus multi-constellation GNSS in a single low-profile housing
• Built for harsh environments: heavy-duty, waterproof enclosure for long-term outdoor use
• Optimized for telematics: designed to support robust connectivity and tracking for mobile and remote assets

Connections

2x 4G/3G/2G LTE MIMO 698~960MHz/1710~2170MHz/2490~2700MHz/3300~3600MHz
1x GPS/GLONASS/GALILEO/BeiDou (Active)

Technical Specifications

Operating Temperature: -40°C to 85°C
Antenna Technologies: MIMO
Cellular Technologies: 4G/LTE
Location: External
Mounting: Screw Mount
Satellite Navigation: GNSS
Type: Combination
IP Rating: IP67
Dimensions: 216*93*31mm RoHS & REACH Compliant
Weight: 415g

4G/3G/2G LTE MIMO (2x)

Frequency: 698~960MHz/1710~2170MHz/2490~2690MHz/3300~3600MHz
Impedance: 50Ω
Polarization: Linear
VSWR: < 3.5
Connector Type: Fakra Code D Jack
Cable Length: 30cm
Cable Type: CFD-200

GNSS (Active)

Frequency: BeiDou:1561.098±2.046MHz; GPS/GALILEO:1575.42±1.023MHz; GLONASS:1602±5MHz
Polarization: RHCP
Impedance: 50Ω
VSWR: 2:1 Max
Gain@3V: 1561MHz:29±3dBi; 1575.42MHz:29±3dBi; 1602MHz:32±3dBi
Connector Type: Fakra Code C Jack
Cable Length: 30cm
Cable Type: RG174
