MA8007.A.001 Antenna External Low-Profile MIMO Router 5G, GNSS, Wi-Fi screw mount Raptor X 7-in-1 IP69K for Emergency and First Responder Vehicles, EV Charger Stations, Smart Industry and Warehouse Applications, Private LTE Networks

Raptor X MA8007 is a low-profile 7-in-1 combination antenna designed for modern routers and gateways, combining wideband cellular MIMO, dual-band GNSS for improved positioning accuracy, and dual-band Wi-Fi for reliable local connectivity.

Its rugged enclosure and permanent screw-mount design make it well-suited for demanding deployments on vehicles, cabinets, and other space-constrained installations where durability and consistent RF performance are required.

• 7-in-1 combination design to reduce installation complexity and antenna count
• Wideband cellular coverage for high-efficiency mobile connectivity
• Dual-band GNSS (L1/L5) to support improved positioning performance
• Dual-band Wi-Fi support for 2.4GHz and 5GHz operation
• Rugged enclosure for harsh environments

Typical applications include:

• Emergency and First Responder Vehicles
• EV Charger Stations
• Smart Industry and Warehouse Applications
• Private LTE Networks

Connections

1x GNSS L1/L5 Bands
4x 5G/4G LTE Cellular 600-6000MHz
2x Wi-Fi® 2.4/5.8GHz

Technical Specifications

Operating Temperature: -40°C to +85°C
Antenna Technologies: MIMO
Cellular Technologies: 5G
Location: External
LPWAN & IoT Communication: NB-IoT, Cat-M
Mounting: Screw Mount, Permanent Mount (M22 Thread)
Satellite Navigation: GNSS
Short-Range Wireless Standards: Wi-Fi
Type: Combination
IP Rating: IP69K
Dimensions: 350mm x 70mm x 39mm M22 Thread IP69K Rated Enclosure IK10 Impact Rated Enclosure
Weight: 840g
Impedance: 50Ω
VSWR: 2:1
IK Rating: IK10

GNSS (Dual-Band L1/L5)

Frequency: 1164-1189, 1559-1592, 1565-1586, 1596-1610 MHz
Polarization: RHCP
Impedance: 50Ω
Peak Gain (dBi): 2.49, 3.93, 3.93, 3.38
LNA Gain (dB): 32.3 (High-Band), 26.3 (Low-Band)
Noise Figure (dB): 2.4 (High-Band), 3.8 (Low-Band)
Input Voltage: +1.8 to 5.5V
Connector Type: SMA(M)
Cable Length: 200cm
Cable Type: RG-174

5G/4G LTE Cellular (MIMO)

Frequency: 600MHz - 6000MHz
Impedance: 50Ω
Polarization: Linear
Radiation Pattern: Omni
Max. Input Power: 2W
Connector Type: SMA(M)
Cable Length: 200cm
Cable Type: TGC-302

Wi-Fi (Dual-Band)

Frequency: 2400-2500, 5150-5850 MHz
Impedance: 50Ω
Polarization: Linear
Radiation Pattern: Omni
Max. Input Power: 2W
Connector Type: RP-SMA(M)
Cable Length: 200cm
Cable Type: TGC-302
