MAX1015.K.002 Antenna External Low-Profile High Performance 5G, GNSS, Wi-Fi 6E/7 screw mount Raptor Max 15-in-1 for Connected Vehicles, Fleet Management, Asset Tracking, Smart Cities

The Raptor MAX (MAX1015) is a low-profile vehicle roof-mount combination antenna designed to consolidate multi-network connectivity into a single rugged enclosure. It supports high-count cellular MIMO, tri-band Wi-Fi coverage for Wi-Fi 6/7 operation, and dual-band GNSS (L1/L5) to improve positioning accuracy versus single-band GNSS solutions.

• 15-in-1 integration: Reduce roof clutter and simplify multi-antenna installations
• Multi-network support: Cellular + Wi-Fi + GNSS in one housing for connected vehicle platforms
• Rugged enclosure: IP67-rated, UV-protected construction suited to harsh outdoor environments

Connections

8x 5G/4G MIMO 617-6000MHz
6x Wi-Fi MIMO 2.4/5.8/7.125 GHz
1x Multiband L1/L5 GNSS Antenna

Technical Specifications

Operating Temperature: -40°C to +85°C
Antenna Technologies: MIMO
Cellular Technologies: 5G
Location: External
LPWAN & IoT Communication: NB-IoT, Cat-M
Mounting: Screw Mount, Permanent Mount
Satellite Navigation: GNSS
Short-Range Wireless Standards: Wi-Fi
Type: Combination
IP Rating: IP67
Impedance: 50 Ω
Polarization: Linear
Dimensions: 330 x 75.5 x 45.2mm RoHS & Reach Compliant

8x 5G/4G MIMO

Frequency: 617-6000 MHz
Standards: 5G/4G, NB-IoT, Cat-M
Impedance: 50 Ω
Polarization: Linear
Radiation Pattern: Omni
Max. Input Power: 10W
Connector Type: FAKRA Code D (Violet)
Cable Length: 500cm
Cable Type: TGC-200 (Braided cable assembly)

6x Wi-Fi MIMO

Frequency: 2.4/5.8/7.125 GHz
Standards: Wi-Fi 6/7
Impedance: 50 Ω
Polarization: Linear
Connector Type: FAKRA Code I (Beige)
Cable Length: 500cm
Cable Type: TGC-200 (Braided cable assembly)

1x GNSS L1/L5 (Active)

Frequency: 1176.45, 1561, 1575.42 MHz
GNSS Bands: L1/L5
Polarization: Linear
Impedance: 50 Ω
VSWR (max.): 3:1
LNA Gain (dB): 29.7 (1176.45 MHz), 28.8 (1561 MHz), 28.1 (1575.42 MHz)
Noise Figure (dB): 2.9 (1176.45 MHz), 2.8 (1561 MHz), 2.9 (1575.42 MHz)
Input Voltage (V): + 1.8 to 5.5
Current consumption (mA): 5 ± 2
ESD protection: IEC61000-4-2 ± 30 kV air / ± 20Kv contact discharge
Connector Type: FAKRA Code C (Blue)
Cable Length: 500cm
Cable Type: TGC-200 (Braided cable assembly)

Download Datasheet PDF
