Description
This rugged omnidirectional fiberglass antenna is designed to provide reliable coverage in the ISM band for long-range, low-power connectivity deployments.
Its collinear design helps deliver consistent 360° horizontal-plane coverage, making it well-suited for reducing node count in wide-area mesh networks and improving overall link stability in demanding environments.
- Designed for: metering, industrial / environmental monitoring, remote asset monitoring, and mesh network deployments
- Durable construction: UV-resistant fiberglass housing for harsh environment use
- Radiation pattern: omnidirectional for uniform azimuth coverage
For a higher-gain option in the same band, see: OMB.433.B06F21 (availability and customization subject to MOQ).
Connector & Cable
- Connector Type: N-Type Female
Technical Specifications
Operating Temperature: -40°C to +85°C
Antenna Technologies: Collinear
Location: External
LPWAN & IoT Communication: LoRa
Mounting: Wall Mount, Pole Mount
Short-Range Wireless Standards: ISM
Type: Single
IP Rating: IP65
Length: 553 mm (Max)
Radome Diameter: 24mm
Bracket Dimension: 70 x 53mm (Max)
Weight: 350g
Impedance: 50 Ω
ISM/LoRa (433MHz)
Frequency: 430-436 MHz
Radiation Pattern: Omni
Polarization: Vertical
VSWR: 1.5:1
Average Gain (dB): -0.48
Peak Gain (dBi): 2.00
Efficiency (%): 89.6
Max. Input Power: 100W
Connector Type: N-Type Female
