Description
This robust omnidirectional outdoor antenna is designed to deliver long-range, reliable coverage for sub-6 GHz 5G and 4G networks. Its rugged bracketed construction and UV-resistant fiberglass radome help support long service life in demanding environments while maintaining consistent performance.
- Omnidirectional coverage: Supports broad-area signal reception and transmission.
- Built for outdoor use: Waterproof housing and durable materials for harsh deployments.
- Flexible mounting options: Suitable for wall-mount or pole-mount installations (bracket included).
- Use cases: Private LTE, CBRS networks, and public safety communications.
Connector & Cable
- Connector Type: N-Type Female
Technical Specifications
Operating Temperature: -40°C to +85°C
Antenna Technologies: Dipole Array
Cellular Technologies: 5G
Location: External
LPWAN & IoT Communication: LoRa
Mounting: Wall Mount, Pole Mount
Short-Range Wireless Standards: ISM
Type: Single
IP Rating: IP65
Impedance: 50 Ω
VSWR: 1.3
Polarization: Vertical
Radiation Pattern: Omni-directional
Max Input Power: 100W
Length: 270mm
Radome Diameter: 24mm
Bracket Dimension: 70*35mm
Weight: 250g
Wind Resistance: >150mph(>241km/h)
5G/4G/3G (Omnidirectional)
Frequency: 1700MHz - 6000MHz
Standards: 5GNR / FR1 / LTE / LTE-Advanced / WCDMA / HSPA / HSPA+ / TD-SCDMA
Bands (as listed): 7, 30, 38, 40, 41, 22, 42, 78, 43, 48, 77, 79
Frequency (Band blocks): 2300~2690 MHz; 3300~3800 MHz; 3200~5000 MHz; 5150~5925 MHz
Peak Gain (dBi): 4.1; 6.1; 7.2; 6.8
Connector Type: N Type Female
