Description
Indoor/Outdoor Omnidirectional Antenna designed for worldwide cellular coverage across key 4G bands, with backward compatibility for 3G/2G networks. This fiberglass omni antenna provides uniform 360° azimuth radiation to help extend coverage and reduce the number of nodes required in a radio network.
The compact, robust fiberglass radome is built for harsh weather environments and is well-suited for outdoor connectivity using cellular routers and modules where durable, long-distance omni coverage is needed.
- Worldwide cellular band support: Covers common 4G bands with 3G/2G fallback support
- Omnidirectional pattern: Consistent azimuth coverage for wide-area deployments
- Rugged outdoor construction: UV-resistant fiberglass housing with IP65 protection
- Flexible installation: Mount to a wall using the pre-installed bracket or to a pole using the supplied U-bolt
Connector & Cable
- Connector Type: N-Type Female
Technical Specifications
Operating Temperature: -40°C to +60°C
Antenna Technologies: Dipole
Cellular Technologies: 4G/LTE
Location: External
Mounting: Wall Mount, Pole Mount
Type: Single
IP Rating: IP65
Dimensions: of 320mm in length and 70mm diameter allow it to be mounted conveniently and uno
Weight: 150g
4G/3G/2G (Omnidirectional)
Frequency: 698-960 MHz, 1710-2700 MHz
Impedance: 50 ohms
VSWR: 1.5:1
Polarization: Vertical (Linear)
Radiation: Omnidirectional
Max Input Power: 150 watts
Peak Gain: 4.5 dBi
Connector Type: N Type Female
