OMB.868.B05F21 Antenna Outdoor High-Gain ISM, LoRa wall/pole mount Barracuda N-Type Female IP65 for Metering, Industrial Monitoring, Security, Smart Cities

Barracuda is an outdoor omnidirectional antenna designed for long-distance coverage in the 868MHz ISM band. Its robust fiberglass housing and UV-resistant coating make it well-suited for demanding environments, helping maintain reliable reception and transmission over range.

Ideal for deployments such as metering, industrial monitoring, and security systems, it also supports narrow-channel M2M network use cases for city-wide device management.

• Omnidirectional radiation for consistent coverage
• High-gain collinear design for extended range
• Weather-resistant enclosure suitable for outdoor installations
• Includes mounting bracket for wall or pole installation

Connector & Cable

• Connector Type: N-Type Female

Technical Specifications

Operating Temperature: -40°C to +60°C
Antenna Technologies: Collinear, Dipole Array
Location: External
LPWAN & IoT Communication: LoRa, SigFox
Mounting: Pole Mount, Wall Mount
Type: Single
IP Rating: IP65
Dimensions: Length 1094mm(Ma x ); Radome Diameter 24mm; Bracket Dimension 70*53mm(Ma x )
Weight: 580g

ISM 868 / LoRa

Frequency: 860~870MHz
Standards: ISM 868
Gain (Max): 5dBi
Polarization: Vertical
Impedance: 50 ohms
VSWR: <1.5:1
Max Input Power: 50 watts
Radiation: Omnidirectional
Vertical Beam-width: 16 Deg
Horizontal Beam-width: 360 Deg
Connector Type: N Type Female
