Description
Barracuda OMB.868.B12F21 is a fiberglass omnidirectional outdoor antenna designed to deliver long-distance coverage in the 868MHz ISM band. Its collinear design provides uniform 360° azimuth performance to help extend range and reduce the number of nodes required in mesh network deployments.
- Omnidirectional coverage: Consistent horizontal-plane radiation for wide-area deployments
- Rugged outdoor build: UV-resistant fiberglass housing for harsh environments
- Designed for LPWAN ecosystems: Suitable for SigFox, LoRa and other LPWA networks
Typical use cases include metering, industrial & environmental monitoring, remote asset monitoring, and mesh network installations.
Connector & Cable
- Connector Type: N-Type Female
Technical Specifications
Operating Temperature: -40°C to +60°C
Antenna Technologies: Dipole Array, Collinear
Location: External
LPWAN & IoT Communication: LoRa, SigFox, LPWA
Mounting: Wall Mount, Pole Mount
Type: Single
IP Rating: IP65
Wind Resistance: >150mph(>241km/h)
Length: 2240mm(Max)
Bracket Dimension: 70*73mm(Max)
Weight: 994g
ISM 868 / LoRa
Frequency: 860-870 MHz
Standards: ISM 868
Radiation: Omnidirectional
Polarization: Vertical
Peak Gain: 11.4dBi
Impedance: 50 ohms
VSWR: <2:1
Max Input Power: 50 watts
Vertical Beam-width: 10 Deg
Horizontal Beam-width: 360 Deg
Connector Type: N Type Female
