Description
Barracuda is a rugged outdoor omni-directional cellular antenna designed for long-distance coverage and reliable reception/transmission across multiple cellular bands.
Its UV-resistant fiberglass housing is built for demanding environments, and the included mounting bracket supports flexible wall or pole installation. It is well-suited for improving cellular coverage in remote areas or challenging indoor/outdoor locations.
Connector & Cable
- Connector Type: N-Type Female
Technical Specifications
Operating Temperature: -40°C to +60°C
Antenna Technologies: Collinear, Dipole Array
Cellular Technologies: 3G
Location: External
Mounting: Wall Mount, Pole Mount
Type: Single
IP Rating: IP65
Length: 298 mm
Weight: 350g
Wind Resistance: >150mph (>241km/h)
Cellular (Penta-band)
Frequency: 824-2170 MHz
Standards: GSM850/GSM900/DCS/PCS/WCDMA I
Peak Gain (dBi): 1.55 (GSM850), 2.13 (GSM900), 4.47 (DCS1800), 4.49 (PCS1900), 4.89 (WCDMA2100)
Average Gain (dBi): 1.18 (GSM850), 1.78 (GSM900), 3.87 (DCS1800), 4.24 (PCS1900), 4.08 (WCDMA2100)
Efficiency (%): 63.4, 75.7, 81.2, 88.8, 87.3
Polarization: Vertical
Impedance: 50Ω
VSWR: <2.0:1
Max Input Power: 50 watts
Radiation: Omni-Directional
Vertical Bandwidth: 65 Deg
Horizontal Bandwidth: 360 Deg
Antenna Type: Collinear
Antenna Design: Dipole Array
Connector Type: N Type Female
