Description
The Barracuda is a penta-band cellular omni-directional antenna designed for long-distance coverage. Its high-gain, all-band performance helps maintain stable reception and transmission, making it well-suited for improving cellular coverage in remote or challenging environments.
- Wide penta-band cellular coverage for multi-network compatibility
- Omni-directional radiation pattern for broad-area signal coverage
- Rugged outdoor-ready construction with UV-resistant coating and fiberglass housing
- Designed for flexible deployment with wall/pole mounting support
Connector & Cable
- Connector Type: N-Type Female
Technical Specifications
Operating Temperature: -40°C to +60°C
Antenna Technologies: Collinear, Dipole Array
Cellular Technologies: 3G
Location: External
Mounting: Wall Mount, Pole Mount
Type: Single
IP Rating: IP65
Length: 595 mm
Radome Diameter: 24mm
Bracket Dimension: 70*35mm(Max)
Weight: 350g
Wind Resistance: >150mph (>241km/h)
Cellular (Penta-band)
Frequency: 824~894, 880~960, 1710~1880, 1850~1990, 1920~2170 MHz
Standards: GSM850, GSM900, DCS, PCS, WCDMA I
Peak Gain (dBi): 3.04, 3.03, 4.30, 4.83, 5.56
Average Gain (dBi): 2.52, 2.76, 3.50, 4.57, 4.63
Efficiency (%): 84.2, 88.7, 77.8, 84.5, 84.2
Polarization: Vertical
Impedance: 50 ohms
VSWR: <2.0:1
Max Input Power: 50 watts
Radiation: Omni-Directional
Vertical Bandwidth: 30 Deg
Horizontal Bandwidth: 360 Deg
Connector Type: N Type Female
