OMB.915.B03F21 Antenna Outdoor External ISM, LoRa wall/pole mount Barracuda N-Type Female IP65 for Metering, Industrial/Environmental Monitoring, Remote Asset Monitoring, Mesh Network Applications

This rugged fiberglass omnidirectional antenna is designed for long-distance coverage in the 915MHz license-free ISM band. Its collinear design provides uniform 360° horizontal coverage to help improve link reliability and reduce the number of nodes required in mesh network deployments.

• Omni-directional radiation pattern for consistent azimuth coverage
• Robust, all-weather design suitable for harsh outdoor environments
• Ideal for long-range ISM/LoRa deployments such as metering and remote monitoring
• Wall/pole mounting support with bracket included

Connector & Cable

• Connector Type: N-Type Female

Technical Specifications

Operating Temperature: -40°C to +60°C
Antenna Technologies: Collinear, Dipole Array
Location: External
LPWAN & IoT Communication: LoRa
Mounting: Pole Mount, Wall Mount
Type: Single
IP Rating: IP65
Dimensions: Length 320mm(Ma x ), Radome Diameter 24mm, Bracket Dimension 70*35mm(Ma x )
Weight: Antenna 280g (Mounting Accessories 70g)
Wind Resistance: >150mph (>241km/h)
Storage Temperature: -40°C to +80°C

ISM/LoRa 915

Frequency: 902~928MHz
Standards: ISM 915
Gain (Max): 3.5dBi
Efficiency: > 61%
Polarization: Vertical
Impedance: 50 ohms
VSWR: <1.5:1
Max Input Power: 50 watts
Radiation: Omnidirectional
Vertical Bandwidth: 78 Deg
Horizontal Bandwidth: 360 Deg
Connector Type: N Type Female
