Description
Omnidirectional outdoor antenna for the 915 MHz ISM band, designed to provide wide-area coverage for long-range IoT and industrial wireless deployments.
The fiberglass radome and rugged construction support reliable operation in harsh environments, while the integrated bracket enables straightforward installation on poles or walls.
- Omni-directional radiation for consistent coverage around the antenna
- Collinear dipole design to support extended coverage distance
- Rugged fiberglass housing designed for outdoor exposure
- Integrated mounting bracket for pole or wall installations
Typical use cases include WLAN, RFID, SigFox, LoRa and LPWA networks operating in the 902–928 MHz band.
Connector & Cable
- Connector Type: N-Type Female
Technical Specifications
Operating Temperature: -40°C to +60°C
Antenna Technologies: Dipole
Location: External
LPWAN & IoT Communication: LoRa, SigFox, LPWA
Mounting: Wall Mount, Pole Mount
Type: Single
IP Rating: IP65
Dimensions: Length 1474 mm(Ma x ), Radome Diameter 24mm, Bracket Dimension 70 x 73mm(Ma x )
Weight: 870g
ISM / LoRa
Frequency: 902-928 MHz
Standards: ISM (902–928 MHz), LoRa, SigFox, RFID
Antenna Type: Collinear Dipole Array
Polarization: Vertical
Impedance: 50 ohms
VSWR: 1.5:1
Gain (Peak): 8 dBi
Max Input Power: 50 watts
Radiation Pattern: Omni-Directional
Vertical Beamwidth: 14 Deg
Horizontal Beamwidth: 360 Deg
Connector Type: N Type Female
